Description
Ride Height Adjustable Shock. The Bilstein B8 5100 Series Front Shock is a ride-height adjustable monotube shock designed for vehicles equipped with front OE coilover-style suspension. It features multiple snap-ring grooves that enable adjustable spring seat positioning to provide front lift with OE springs, depending on the application.
Construction and Appearance. This shock absorber features a durable monotube design with a 46mm digressive piston and zinc plated finish to resist corrosion. The 2.0-inch diameter body is engineered with multiple snap-ring grooves to enable adjustable spring seat positioning for lift adjustment.
Installation. Installation is straightforward and does not require drilling or complex modifications. It bolts directly to existing mounts using the bar pin lower and stem upper mount design for a secure fit.
Warranty. The product includes a limited lifetime warranty, ensuring long-term reliability and quality assurance.
Application. Designed to fit 2014–2018 Sierra 1500 models and other compatible GM trucks, providing up to 3 inches of front lift while maintaining compatibility with front OE coilover-style suspension and OE springs.
Bilstein 24-238304
CA Residents: WARNING: Cancer and Reproductive Harm
- Suspension Shock Absorber
- B8 5100 Series Front Ride Height Adjustable
- Weight 7.75 Pounds
- Collapsed Length 15.00 Inches
- Extended Length 18.89 Inches
- Stroke Travel Length 3.89 Inches
- Lower Mount Type Bar Pin
- Upper Mount Type Stem
- Internal Design Monotube
- Finish Zinc Plated
- Reservoir No
- Body Design Snap Ring Grooved Body Coilover
- Body Diameter 2.0 Inches
- Piston Diameter 46 Millimeters
- Boot Not Included
- Spring Seat Included
- Shaft Diameter 14 Millimeters
- Adjustable Damping Non-Adjustable
- Country Of Origin Mexico
- Quantity Per Vehicle Two
- Fits 2014-2018 Sierra 1500
| Brand | Bilstein |
| Shock Type | Adjustable |
| Shock Lift Height | 0 to 1.75-Inch Lift |
